S&T Cobra D+1 Scenario

This is a scenario for the Strategy and Tactics Edition 251magazine game "Cobra", which is itself a remake of the old classic SPI game "Cobra". The original game came with an expansion which covered the actual D-Day landings as well as the build up before the actual Cobra breakout. The magazine game re-presented this expansion in a more integrated format.

The problem with the expansion I have found however was that it was very difficult to get a historical or close to historical result for the landing, usually as a result of the beach combat table being very prone to dice luck (or not) as well as the movement sequence on the first turn not really making the actually allied advance inland on the 6th of June readily possible.

This scenario attempts to portray the situation at midnight on the 6th of June, effectively starting the game at D+1, or game turn 2. This allows for a battle of the build up from a solid historical base. Units are positioned as far as know to there locations at the start of the 7th of June, 1944, with historical loss levels.

The scenario creates the issues and opportunities that both sides faced on the 7th. The germans can hurl the 12 SS at one selected target, either the 6th Airborne lodging, or the Sword beach units and cause potentially considerable damage in spite of naval and air support. However, this risks leaving units to the west dangerously unsupported, and a major danger of a breakout east of Bayeux. In reality the safe course is to break up the panzer divisions and brace the damaged infantry divisions with them.

Around Omaha and Utah, containment is the word of the day, falling back to Carentan whilst trying to bring in more reinforcements.

On the allied side the days aims are to link Sword with Juno and remove the remnants at Douvre, whilst building up the British lodgement and attempting to link with Omaha and strengthen the 6th airborne. Omaha needs to slowly expand to allow more units to land. Likewise Utah needs to consolidate and land fresh infantry divisions to begin the drive to link to Omaha and also cut the peninsula.

Game Start
The game starts with the start of game turn 2. All rules for the expansion (i.e. the Build Up scenario are in effect). Weather for this turn (only) is fixed at Overcast. All invasion beach hexes have been captured by the allies.

Extra Rules
The following house rules I have found work well with Cobra.

14.6.5 Defensive Shore Bombardment
The allies may use defensive shore bombardment to help defend against axis attacks. Shore Bombardment defends at the same ranges as per offensive shore bombardment. However, only 1 shift can be gained from defensive shore bombardment  and an NSP expended on defensive shore bombardment cannot be then allocated in the Allied player turn to offensive shore bombardment.

14.5.2 Carpet Bombing The carpet bombing rules in Cobra don't really make sense as they disallow the allies attacking hexes being carpet bombed nor advancing into those hexes in the mechanized movement phase. Serious carpet bombing was almost always accompanied by a subsequent ground attack. The aim of the carpet bombing was to exploit through that area, the problem however being the inherent destruction caused to the road net. Therefore the following replaces 14.5.2
Allied units must attack the hex which is carpet bombed, irrespective of the carpet bombing result. No additional air power points may be used in this attack. In addition, one shift to the left benefitting the defender occurs, simulating difficulties in attacking through the churned up terrain. The allies may advance after combat into the carpet bombed hex if vacated, but no further irrespective of the result. During the subsequent mechanized movement phase, the carpet bombed hex costs 7 movement points for mechanized units or 4 movement points for infantry to leave. In addition, no road if any in the carpet bombed hex exists for that turn into or out of it.
If the the hex being carpet bombed is city hex, no exploitation from the hex is allowed.
Setup
The following lists the setup of units for the Cobra D+1 scenario. Units marked with a * have lost one step. Map B Locations are on the "Invasion" map (i.e. the map with Cherbourg and the landing beaches on it, whilst map A locations are on the "Breakout" map (i.e. the classic Cobra map covering the southern part of Normandy). Maps locations are on the S&T Cobra maps.

US

Unit	Location	Notes
1st Infantry Division	B3319*	Omaha Beach East - Effectively has 1 regiment non-effective after landing
4th Infantry Division	B2215	Landed Utah - moved inland mainly wheeling north
29th Infantry Division	B3118*	Omaha Beach West - one regiment down due to landing losses
505/82nd Airborne Regiment	B2016	St-Mere Eglise
507/82nd Airborne Regiment	B1815*	Badly scattered and in swamps
508/82nd Airborne	B1917*	Badly scattered and in swamps
501/101 Airborne Regiment	B2217
502/101 Airborne Regiment	B2215*	Badly scattered - Predominantly most of serials landed on northern side of Utah lodgement
506/101 Airborne Regiment	B2218
2+5 Ranger Btns	B2816	Point du Hoc - In reality only a few companies landed here, the majority landed on the west end of Omaha beach.

UK

Unit	Location	Notes
3rd Infantry Division	A3602	Sword Beach - Advanced to Lebisey before successfully fending off 21st Panzer counter attack.
50th Infantry Division	A3002	Gold Beach - lead elements penetrated as far as the Bayeux-Caen Road before pulling back.
3/6th Airborne Regiment	A3904
5/6th Airborne Regiment	A3803
6AL/6th Airborne Regiment	A3803
8th Armoured Brigade	B3820
27 Armoured Brigade	A3501
1SS Brigade	B3619	Advancing on Port-en-Bassin
4SS Brigade	A3903	Reinforced 6AB lodging after advancing across Pegasus bridge.

Canada

Unit	Location	Notes
3rd Canadian Division	B3302	Juno Beach
2nd Canadian Armoured Brigade	B4320	Juno Beach

German

Unit	Location	Notes
1057/91	B1816*	Attempting to push on St-Mere-Eglise - battles of Chef le Pont causeways
1058/91	B2015	Attempting to push on St-Mere-Eglise from North with Stug IIIs.
6FJ/91	B2119*	Damaged in trying to advance on St-Mere-Eglise and also trying to disengage in early hours of 7th of June.
920/243	B0811	West Coast Division - largely did  not move on 6th of June
921/243	B0917
922/243	B2114	Advanced on 6th to north of Utah. Arrived at night.
914/352	B2817	Based between Isgny and Carentan. Belatedly arrived near Omaha beach and partially engaged Rangers at Point du Hoc.
915/352	A2903*	Spend D-Day chasing phantom paratroopers south of Bayeux before returning northwards late in the day to be badly dealt with by advance from Gold Beach.
916/352	B3119*	Main defensive unit on Omaha beach. Defended well but badly damaged by end of day.
729/709	B1807	Cherbourg Unit
739/709	B1309	St Pierre Eglise
919/709	B2214	Defended Utah beach in part for probably less than an hour, then northern flank of Utah lodgement
731/711	A4101	Advanced from Trouville on D-Day towards 6th Airborne lodgement
744/711	A4201	Advanced from Trouville on D-Day towards 6th Airborne lodgement
763/711	A4301	Advanced from Trouville on D-Day towards 6th Airborne lodgement
708/716	A3202*	This appears a misprint as there is no record of a 708th regiment of the 716 Infantry Division. I have tried to place it where elements of the 736/716 were retreated to.
726/716	B3520*	Elements of the 716 were on most beaches from Sword to Omaha on D-day. This regiment defended the eastern end of Omaha beach through to the Bayeux sector. By the end of the day it appears to have fallen back to the north west of Bayeux after being damage somewhat.
736/716	B4420*	Douvres fortified area - 736 was split 3 ways. Part was left north of the 6 Airborne lodging, remnants fell back west of Caen, and some parts retreated into the Douvres complex. Basically almost destroyed on D-Day. Hard to place in this scenario.
FJT	B1208	Reserve unit in the Cherbourg peninsula.
1 Flak Regiment	B3019
30 Flak Regiment	B1509
32 Flak Bataillon	B2618
922 Flak Bataillon	B1208
100/21 Panzer Regiment	A3603*	Damaged from advance to coast at Lion-sur-Mur in the late afternoon. A combination of 6lb ATGs, Sherman Fireflys and Priest destroyed or damaged 40+ of the regiments tanks. Withdrew to north of Caen at end of day.
125/21 Panzer Grenadier Regiment	A3704	Recon batallion of 21st Panzer sent against 6th Airborne landing area early on the morning of 6th, drawing in more forces. 125 PzG regiment placed north of Caen facing 6th AB late on the 6th.
192/21 Panzer Grenadier Regiment	A3603	Advanced to coast with 100th panzer regiment. Took surprisingly few losses. Fell back to north of Caen at end of day.
30 Panzer Batallion	A2402	Misnomer. Should probably be 30th Regiment or 30th Mobile group depending on sources. Advanced to Bayeux area on D-Day from Coutances area. Elements present near Omaha beach, but not heavily engaged. Location is approximate at best.
12/12 SS Panzer Regiment	A3605	Road march to Caen on D-Day. Preparing for counter attack on 7th/8th which never happened.
25/12 Panzer Grenadier Regiment	A3404	Road march to Caen on D-Day. Preparing for counter attack on 7th/8th which never happened.
26/12 SS Panzer Grenadier Regiment	A3807	Road march to Caen on D-Day. Preparing for counter attack on 7th/8th which never happened.
LXXXIV Corp HQ	A1606	In St Lo. Did not move.

Blast from the past - HTMLR - HTML Refresh

Well time to start putting some posts on this blog for real. And I though i might start with a blast from the past. This is where my head was in 1997, when Dot Coms were just starting for real... This is the spec I put up to the IETF for a HTML Refresh language. Today you could most probably achieve a similar result with AJAX, but not nearly as easily or efficiently as if it was built into HTML and parse natively by the browser (but maybe a bit more flexibly and extensibly).

Anway, hope you enjoy and that it stimulates some more ideas:

Heres the original IETF Draft - http://tools.ietf.org/html/draft-rfced-exp-nelson-00

And the Text of it:


INTERNET DRAFT EXPIRES APR 1999 INTERNET DRAFT
R. Nelson
12 October 1998
Category: EXPERIMENTAL



HTML REFRESH LANGUAGE (HTMLR/1.0)


<draft-rfced-exp-nelson-00.txt>

Status of This Memo

This document is an Internet-Draft. Internet-Drafts are working
documents of the Internet Engineering Task Force (IETF), its
areas, and its working groups. Note that other groups may also
distribute working documents as Internet-Drafts.

Internet-Drafts are draft documents valid for a maximum of six
months and may be updated, replaced, or obsoleted by other
documents at any time. It is inappropriate to use Internet-
Drafts as reference material or to cite them other than as
"work in progress."

To view the entire list of current Internet-Drafts, please check
the "1id-abstracts.txt" listing contained in the Internet-Drafts
Shadow Directories on ftp.is.co.za (Africa), ftp.nordu.net
(Northern Europe), ftp.nis.garr.it (Southern Europe), munnari.oz.au
(Pacific Rim), ftp.ietf.org (US East Coast), or ftp.isi.edu
(US West Coast).


Distribution of this document is unlimited.


Copyright Notice

Copyright (C) Ross Nelson (1998). All Rights Reserved.

Abstract

This document describes HTML REFRESH, an EXPERIMENTAL language
and protocol for refreshing HTML pages and allowing serious
thin-client/server applications via HTTP [RFC2068].

1. Rationale and Scope


HTML forms have changed little in functionality or feature since
the inception of the HTML standard. Whilst HTML forms allow the
submission of form data from visible and hidden fields up to a
server side CGI program (or some derivative thereof), the results
must come back as a complete HTML page, either in the existing
window/frame or in another browser window or frame.

This is particularly tedious as the entire target page needs to
be redrawn, even if only certain data elements have been changed.
This has two very negative affects. Firstly, the bandwidth
requirements are increased as the entire page format must be sent
down to the browser again and not just the "field" data which has
changed. Secondly, the affect of redrawing the entire screen does
not allow the development of user friendly thin-client/server
applications (where the client is the web browser)and currently
leads to user disorientation.

Various browser "add-ins", such as "Java" have been developed
whilst HTML forms have largely been allowed to languish. This is
extremely unfortunate as by far the largest number of transactions
over the Internet occur via HTML forms.

This document specifies a HTML REFRESH language, which permits
the refreshing of the form data elements and images on a HTML
browser page without the redrawing of the entire page. This
allows serious user interfaces to be developed whilst using
less bandwidth to do so.

Future versions of this protocol may include extensions for
refreshing non-form elements of a web page, in-line with DHTML
standards.

2. HTML REFRESH LANGUAGE

The HTMLR language is built using the concepts of the HTML
language and is to be used in web browsers in conjuction
with HTML. Needless to say the main delivery method for
HTMLR is HTTP, with the use of a new mime-type.

2.1 HTTP Added mime-type

The HTTP would allow the following mime-type through to the
browser and the web server and browser would comprehend it.
The mime-type is :

text/htmlr

which would denote the content which followed as a HTML refresh.
A HTML REFRESH aware browser would acknowledge the mime-type
and note not to redraw the target page from scratch but instead
integrate the results with it.

2.2 HTMLR Language


The HTMLR Language uses HTML like syntax to denote the refreshes
that are to be made to a HTML page. The following tags and
attributes are used to specify these refreshes. Each tag is
covered below with accompanying description and example.

It is anticipated that HTMLR response pages would be generated by
existing CGI (or like) capable programming languages, for example
PERL, ASP, COLD FUSION, etc. Such languages should be easily
capable of generating HTMLR and also changing the response
mime-type.

2.3 HTMLR TAGS


2.3.1 HTMLR


Syntax:
<HTMLR> ... </HTMLR>

Description:
The HTMLR tag denotes that the all tags and text until the /HTMLR
tag comprise a refresh of the existing HTML page/frame as
displayed by the browser. This tag is equivalent in import to the
<HTML></HTML> tags. Upon encountering a HTMLR tag, a browser
should not clear the existing HTML display page/frame, but rather
interpret the contents of the HTMLR tag and apply the relevant
processing to the current page.

Valid tags within HTMLR tags are specified in the rest of this
section.

Example:
<HTMLR>
..... refresh tags ....
</HTMLR>

2.3.2 WITHFORM


Syntax:
<WITHFORM NAME="form-name">....</WITHFORM>

Description:
The WITHFORM tag denotes which form the tags within it apply to.
The form-name specified with the NAME parameter must match the
name of an existing form on the currently displayed page. The
browser should treat all tags encountered within the WITHFORM
screen as dealing with the specified form where applicable.

Tags which are affected by the WITHFORM tag are SETINPUT,
SETTEXTAREA,CLEARINPUT,WITHSELECT.

If WITHFORM does not enclose these tags, they are deemed to be
relating to the first form on the current page.

Example:
<HTMLR>
<WITHFORM NAME="Person">
.... refresh tags for person form .....
</WITHFORM>
</HTMLR>


2.3.3 CLEARINPUT

Syntax:
<CLEARINPUT {EMPTY|DEFAULT}>

Description:
The CLEARINPUT tag clears all fields/checkboxes/radiobuttons/
textareas/buttons in the currently targeted form and resets them
to either empty or their default values. The targeted form is the
one specified in the enclosing WITHFORM tag, or in the absence
of this, the first form on the page. This should be processed in
sequence by the browser, thus any subsequent SETINPUT tags would
set the fields away from their default or empty values.

The EMPTY attribute sets the fields to empty whilst the DEFAULT
attribute set the fields to the original default value as
specified in the original HTML page.

Example:
<HTMLR>
<WITHFORM NAME="PERSON">
<CLEARINPUT EMPTY>
</WITHFORM>
<STATUS VALUE="Person Record Added">
</HTMLR>


2.3.4 SETINPUT


Syntax:
<SETINPUT NAME="field-name" VALUE="new-value" {CHECKED|UNCHECKED}
{DISABLED|ENABLED}>

Description:
The SETINPUT tag sets the input-field to the new-value specified
in the VALUE parameter. For radio button and checkbox fields, the
CHECKED/UNCHECKED parameter can be specified to alter the field
appearance. The field-name, specified in the NAME parameter must
match the name of a field (hidden/text/radio/checkbox/button) in
the targeted form on the current page. The targeted form is the
one specified in the enclosing WITHFORM tag, or in the absence
of this, the first form on the page. For radio button fields,
the new-value must also match the existing value of the named
field in the current form.

The HTML 3.0 proposed (but not widely implemented) DISABLED
parameter could also be used in SETINPUT, along with ENABLED to
dynamically enable/disable the input field.

Example:
<HTMLR>
<WITHFORM NAME="Person">
<SETINPUT NAME="Name" VALUE="Fred Jones">
<SETINPUT NAME="Dob" VALUE="26/Jan/1971">
<SETINPUT NAME="Address" VALUE="35 Fred Street, Springfield">
<SETINPUT NAME="Sex" Value="MALE" CHECKED>
</WITHFORM>
</HTMLR>

2.3.5 SETTEXTAREA

Syntax:
<SETTEXTAREA NAME="field-name" {ENABLED|DISABLED}
>new-value</SETTEXTAREA>

Description:
The SETTEXTAREA tag sets the input-field to the new-value
specified before the closing /TEXTAREA tag. The field-name,
specified in the NAME parameter must match the name
of a textarea field in the targeted form on the current page.
The targeted form is the one specified in the enclosing WITHFORM
tag, or in the absence of this, the first form on the page.

The HTML 3.0 proposed (but not implemented) DISABLED parameter
could also be used in SETTEXTAREA, along with ENABLED to
dynamically enable/disable the textarea.

Example:
<HTMLR>
<WITHFORM NAME="Person">
<SETTEXTAREA NAME="Comments">
The comments for this record are these
</SETTEXTAREA>
</WITHFORM>
</HTMLR>

2.3.6 SETFOCUS

Syntax:
<SETFOCUS FORM="form-name" FIELD="field-name">

Description:
The SETFOCUS tag set the input focus the field/textarea/selectlist
/checkbox/radiobutton-set/button with the name specified by the FIELD
parameter. The form the field is in is specified by the FORM
parameter. This tag is not affected by the WITHFORM tag as it
must set a definitive focus for the entire page, regardless of
how many forms are present.

Example:
<HTMLR>
<MSGBOX>You must enter an Name</MSGBOX>
<SETFOCUS FORM="Person" FIELD="Name">
</HTMLR>

2.3.7 WITHSELECT

Syntax:
<WITHSELECT NAME="field-name" {DESELECTALL} {REMOVEALL}
{ENABLED|DISABLED}></WITHSELECT>

Description:
The WITHSELECT tag is used to choose and set a select list
object in the current form. The field-name, specified in the
NAME parameter must match the name of a select list object
in the targeted form on the current page. The targeted form is
the one specified in the enclosing WITHFORM tag, or in the absence
of this, the first form on the page.

The DESELECTALL parameter immediately de-selects all existing
items in the select list. The REMOVEALL parameter immediately
removes all items from the select list.

The HTML 3.0 proposed (but seldom implemented) DISABLED parameter
could also be used in WITHSELECT, along with ENABLED to
dynamically enable/disable the SELECT list.

Example:

<HTMLR>
<WITHSELECT NAME="Continent" CLEARALL ENABLED>
<SETOPTION SELECTED>Asia</A>
</WITHSELECT>
</HTMLR>

2.3.8 SETOPTION

Syntax:
<SETOPTION {ADD|DELETE} SELECTED|DESELECTED
VALUE="return-value">display-value</OPTION>

Description:
The SETOPTION tag is used to add, alter, or delete a select
list item of the current SELECT list object. The current select
list is the select list named by the last WITHSELECT within the
currently targeted form. The SETOPTION tag is invalid outside of a
WITHSELECT. The targeted form is the one specified in the
enclosing WITHFORM tag, or in the absence of this, the first form
on the page.

The ADD/DELETE parameter is used to add and delete items
respectively from the SELECT list. The SELECTED/DESELECTED
parameter is used to select/deselect an item after it has been
created, or if it already exists, to alter it.

Example:
See WITHSELECT tag example

2.3.9 MSGBOX

Syntax:
<MSGBOX {TITLE="title"}>message</MSGBOX>

Description:
The MSGBOX tag displays a centered message box to the user with
message supplied before the </MSGBOX> parameter enclosed in it.
The message box must be modal and have an 'OK' button to allow
the user to proceed. The browser should process the MSGBOX tag
immediately before parsing/processing any more of the HTMLREFRESH.
The optional TITLE parameter specfies a title for the messagebox
window.

The text between MSGBOX and /MSGBOX tags should not contain HTML
formating and browsers may wrap the text as well as obey CRLF
combinations found in the text.

The MSGBOX tag allows for easy server generated intrusive messages
without affecting the browser page display.

Example:
<HTMLR>
<MSGBOX TITLE="Update Successful"
>The Record has been updated.</MSGBOX>
</HTMLR>

2.3.10 STATUS

Syntax:
<STATUS VALUE="status-line-value">

Description:
The STATUS tag is used to place the value specified in the VALUE
parameter into the status line at the bottom of the browser
window.

The STATUS tag allows for another form of easy server generated
intrusive messages without affecting the browser page display.


Example:
<HTMLR>
<STATUS VALUE="Please correct the value in the Age Field.">
<BELL>
</HTMLR>

2.3.11 PRINT and PRINTURL

Syntax:
<PRINT {TO=printer-name} {ORIENT=orientation} {TRAY=traynumber}
{COPIES=copy-count}>....</PRINT>
<PRINTURL {TO=printer-name} {ORIENT=orientation}
{TRAY=traynumber} {COPIES=copy-count} SRC="url">


Description:
The PRINT tag is used to print HTML to the specified printer.
The HTML to print is supplied between the PRINT and /PRINT tags.
The print is sent to the printer specified by the optional TO
parameter. If no TO parameter is specified, a printer dialog
should be displayed for the user to select a target printer
from. Printing should occur in parallel to any other browser
processing. The TO option is of most value in an intranet
environment.

The ORIENT, TRAY and COPIES parameters are all options which
allow control over the printing process. The ORIENT parameter
can be used to specify "landscape" or "portrait" printing. The
TRAY parameter can be used to select a paper source. The COPIES
parameter can be user specify an number of copies to print. All
are optional and are most suited to intranet systems.

The PRINTURL tag functions the same as the PRINT tag in terms of
parameters, except that the content to print is supplied by the
url specified in the SRC parameter. The browser should open the
specified url and print the resultant stream as requested. The
printing method should be dictated by the mime-type returned.

Browsers should aim to support multiple PRINT requests in a
single HTML REFRESH stream.

The HTML allowable between the PRINT and /PRINT tags should be
of the same conformance level as the normal HTML supported by
the browser and print exactly the same as a user activated print
of a normal web page.

Example:
<HTMLR>
<MSGBOX>The person record will now be printed to your
"HP" printer.</MSGBOX>
<PRINT TO="hp01" ORIENT="portrait" TRAY="3" COPIES="1">
<HTML>
<HEAD>
<TITLE>Person Record 123321</TITLE>
</HEAD>
<BODY>
<H2>Person Record 123321</H2>
<B>Name:</B> John Smith<BR>
<B>DoB: </B> 14/Mar/1969<BR>
<B>Address: </B> 14 James St Smithville<BR>
<HR>
</BODY>
</HTML>
</PRINT>
</HTMLR>

2.3.12 BELL

Syntax:
<BELL>
Description:
The BELL tag makes the browser produce an audible or visible bell.

Example:
<HTMLR>
<BELL>
<MSGBOX>The server has detected an error.</MSGBOX>
</HTMLR>

2.3.13 SETIMG

Syntax:
<SETIMG NAME="image-name" SRC="url">
Description:
The SETIMG tag is used to set images to new images based on a new
URL. The "image-name" given in the NAME parameter must match the
name of an image on the current HTML page. The new image is loaded
into the same screen area as specified by the original IMG tag on
the original HTML page.

The browser will place the new image on the page in the same
location as the old image, with the same dimensions to avoid
page resizing.

Example:
<HTMLR>
<SETIMG NAME="EmployeePic" SRC="/images/employee/002012.jpg">
</HTMLR>


3. Operational Constraints and Implications


3.1 Web Servers

Web servers may require configuration to allow the text/htmlr
mime-type to be transmitted from the CGI program.

3.2 Web Browsers

Web browsers will naturally be required to support the protocol
with substantial internal changes. On reciept of a HTML REFRESH
of a given page, the page will not be redrawn but instead the
fields altered as required. The refresh should NOT be placed in
any history or "BACK" button cache as this does not make sense.

3.3 Javascript/VBscript Implications

Javascript/VBscript browser implementations could possibly be
extended to support an "OnRefresh" event in a similar manner
as the existing "OnLoad" event. This event would be triggered
upon receipt and application of a HTML REFRESH to the page.
Appropriate extensions to the HTML BODY tag syntax would need to
be made to support the "OnRefresh".

3.4 CGI Programs

CGI program authors would gain the freedom to write serious
thin-client/server applications with HTML REFRESH. For example,
a HTML page could have buttons to move forward and backward
though records in a database. Upon pressing either button, a
submission would be sent to the appropriate Web Server/CGI
program. It would navigate the the next/previous database row and
return new data for the HTML form fields using a HTML REFRESH.

This refresh would only alter the values in the HTML FORM fields
on the page, thus lessening bandwidth requirents, aiding
usability and removing redundant page redraws.

3.5 Security

HTML REFRESH pages would travel under HTTPS the same as HTML and
therefore enjoy the same security benefits.

4. Acknowledgements


Thanks in particular to Steve Aldred, Nigel Williams and last but
not least Joanna Ladon for encouragement and review.

5. References


[RFC2068] Fielding, R., Gettys, J., Mogul, J., Frystyk, H., and T.
Berners-Lee, "Hypertext Transfer Protocol -- HTTP/1.1", RFC 2068,
January 1997.


6. Author's Address


Ross Nelson



INTERNET DRAFT EXPIRES APR 1999 INTERNET DRAFT

WikiParts

Whats this about?

Ever wanted to show on a wiki page the information that you've collaborated on as well as some structured data from a corporate data source, external web service or some other system of truth? Well read on...

Genesis

Recently I was working on an prototype Enterprise Architecture Wiki. Basically it contained information about applications, installations, infrastructure (software and hardware) and pretty much most of the IT capabilities of an organisation. Someone pointed out that some of this knowledge was already in another structured datasource, which was backed by a traditional database. This informaiton was reliable and pretty much the record of truth and what they thought would be good would be a fusion of that information with the power and function of a wiki.

So the basic idea was born. Fuse the knowledge reliability of traditional data sources with the power and function of a wiki. Note that I say data sources and not database. A data source could be a database, a web service or an external application, all positioned behind a web service. Think of a mashup between a wiki and, well, anything!

What it may look like in practice...

Imagine a wiki that has some details about high value customers that your elite sales team targets. We are talking an Enterprise 2.0 (thats Web 2.0 inside an organisation on an intranet) wiki here, where we have multiple pages, one per high value customer.

On these pages we put information about the customer, sales people add notes, ideas on strategies for up-selling, their known preferences, links to other customers who are know acquaintances, etc. The problem is we already have a customer database sitting on a corporate server.

Its the system of record for the customer, their contact details, basic sales history, etc. We dont want to duplicate that information in the wiki and have to update details in two places, or worse still let them get out of sync. Likewise our existing Line-Of-Business sales system is too inflexible to allow for collaboration on customer information or easy navigation.

Enter the WikiPart. On the wiki page we have some information that comes from standard wiki page editing. But also we have other information that comes via WikiParts from external data sources, external to the wiki that is. For example, the sections that have the customer name, DOB, contact details, current total sales worth etc, are brought in via WikiParts from our existing sales system database.

The rest of the page is strictly wiki. Users can create and edit, notes, informaiton, strategies and add wiki links as required.
This is just one example. But think about it. Theres probably a million others just waiting out there just waiting to be fused together...

Actual Implementation...

Im trying to run over how this might be implemented at a high level in MediaWiki, mainly because its widely used and also already has an existing rich syntax that could be extended.

In MediaWiki I see basically two items that wiki users would add to a page. The first is the WikiPart which provides the linkage to the web service that accesses the data source.

The second is the parameter substitution that allows the use of this data in the Wikis page. So at the top of the wiki page there may be something like:

{{
WikiPart
id="CustomerWikiPart"
service="http://corporatesystems/salesdata"
parameters={customerId=13266}
}}

This would cause the wiki server to call the web service "salesdata" with a message containing a parameter called "customerId with a value of 13266. The service would then query the sales system (or its database direct) and return a variety of values as part of the web service return message (such as the customers name and address contact details).

These values could then be parameter substituted into the wiki page. A typical wiki page that utilises this web service output may be as follows:

==Customer
ID==
{{{CustomerWikiPart.customerId}}}
==Name==
{{{CustomerWikiPart.customerName}}}
==Contact
Address==
{{{CustomerWikiPart.streetAddress}}}
==Mobile==
{{{CustomerWikiPart.mobile}}}
==Notes==
This customer has said previously he is interested in our [[super widget]] and [[wonder widget]] products but that the price was too high at that time. He is known to like golf and drives and old Jaguar.

As you can see I've glossed over the web service details and message syntax. For now I've tried to keep it high level to get feedback. In reality, most of what has been shown in the example above would be done on page templates.

You would probably set up a "Customer" page template with all the substitutions and initial wiki part in place. In the actual wiki page that utilises the template, the value for the customerId would need to be specified and utilised when the template is evaluated on the wiki server. Again i'll leave details till another time.

Other wiki products would have similar approaches. However some like the Wiki offering in Microsoft's Sharepoint 2007 may need a slightly different approach. It relies on an advanced page editor (think a very simple web version of MS-Word) and supports no other mark up other than wiki links.

It does however allow the Wiki page to be Web Part "edited" which allows you do put web parts around the wiki page (but not really in it), so there is scope for developing a .Net WebPart that does the job I described above, though the current look and feel may not be particularly integrated.

And for extra merit points....

The true pleasure and pain of WikiParts is when they become a two way street. Thats where wiki pages retrieve information from the web service, and also update it. When a page is edited, or maybe even created, the wiki server could place dialog boxes on the page for editing (or input) of values that are linked to WikiParts. On submission, the values would be sent via the WikiPart and web service to the datasource, whilst the standard wiki text would also be updated. The input fields would default to their current values on an edit.

Of course the pain here is the input validation. The data consistency of the underlying datasource must be preserved. It needs to enforce such rules as does the web service implementation operating over it and reflect any violations back to the wiki server in a reasonable manner. In addition, some level of client side data editing functionality (i.e. list boxes of possible values, range and field length checking) would have to be specifiable to provide users with a reasonable experience.

Again this is far in the future, and there are probably many WikiPart based wikis that would simply be read only from the external data source. But again the posibilities for merging structured and semi-strucutured data in enterprise wikis are enticing.

Wrapping Up

So there you have it, WikiParts. Merging information and data. Combining what previously was lost in Word documents in a file share and what was locked up in corporate databases, into one collaborative envrionment. And being web service based, almost any data external to the wiki can be accessed and merged into the displayed page.

Maybe a wiki product out there is doing this already, or something similar. There are literally hundreds of wiki products on the market or available as opensource or freeware. I havent surveyed that many and it wouldnt surprise me. I suspect someone may have also already hand hacked an opensource wiki to incorporate such a feature.

But I suspect this hasn't appeared in the mainstream products yet and it needs to soon, to completely unlock the power of wikis, collaboration and structured data combined for the first time.

New Blog - Enterprise Architecture by Wiki

I've just started a new blog devoted to my Enterprise Architecture By Wiki concept and it can be found here at http://eabywiki.blogspot.com/. I'll still be posting here from time to time.

Comet McNaught Take 4

My fourth set of Comet McNaught images. This time from a dark skies site about 35km NNE of Canberra. There was no cloud for the first 30 minutes after comet sighting but it slowly rolled in. Inspite of this some very nice images of the comet and the immense arcing striated tail, which im guess doesnt completely set till midnight.

Conditions were not ideal however due to blasting winds and a large amount of dust from the drought affected fields. The Moon is also just about to start having an affect on viewing. Please enjoy these shots and an Orion starfield for good measure!

Comet McNaught Take 3

Last night (21-01-07) the trough of bad weather crossing SE Australia cleared from the ACT region at just the right time. Within about 1.5 hours before sundown a hole developed to the SE and widened with only low cloud hanging on the bridabellas and passing scud. Comet McNaught again looked fantastic with the striations in the tail clearly visible and a giant arc to the north being faintly suggested. The nucleus was lost about 30 minutes before it would normally set in a cloud bank but it was about to enter ground haze anyway. The comet may have been slightly darker than the previous night but still incredible. A two day old moon was visible but quickly set. In another 2 days it will start to disrupt the viewing I think. The better photos are below.

Comet McNaught 2nd Take

Here are my second set of mc naught photos from 20-Jan-07. Absolutely brilliant comet though i wasnt in the right location. Still great amazement and fun had by all. The tail stretched 15 degrees where i was but could only get so much in FOV due to street lighting around.

Comet McNaught First Take

The following are the first shots of Comet McNaught from Mt Ainslie in Canberra on the night of 15-Jan-2007. Conditions were at best poor with heavy smoke haze from bushfires up to about 5 degrees above the western horizon and decreasing from their up. I picked up the comet about 5 minutes after sunset whilst looking at an aircraft. Tracked all the way till around 8:50pm when it was lost by all in a heavy haze bank near the horizon (all but the man with the IR camera that is!).

Comet was naked eye visible for about 5 mins but only marginally due to poor conditions. It was visible in scopes and binoculars from sundown till about 10 mins before it set.

Shots were taken prime focus with Skywatcher 6" Refractor (fl=1200) using Cannon EOS 400D DSLR at various ISO and speed settings. More tomorrow night!

Click on images below to enlarge. Some nicer tail and nucleus detail in the enlargements.

Enola Gay

Just saw a program on the History channel about the atomic bombs at the end of the second world war. A quick check with Google Earth shows that the pits used to load the bombs are easily visible from space, as is the airfield. Well, most of tinian shows up as an airfield or base area for that matter.

The two pits are visible here:

15.083391993, 145.634355494

with the airstrips visible running east to west just below.

Whats with Gilze Air Force Base?

Years ago I cycled past Gilze Air Force Base in the Netherlands and almost got decapitated by an F16. It was my own stupid fault really as there were traffic lights on the road to stop cars whilst aircraft were on final. I rode past these to get a good photo head on of an F16 on approach. So close it was I felt the exhaust heat as it passed over and the ditch next to the road was utilised, much to the amusement of a certain cycling companion!

Last night I was looking at it in Google Earth only to be astonished that the Air Force base has been pixelated into oblivion. The road I was on is clearly visible in hi-res with cars going along it to the west of the west end of the main east-west runway. But the entire base has been crudely pixelated so as to be unviewable.

You can find it here:

51.5667226748, 4.93937926653

[Just push the "Fly To" tab in the top left of Google Earth, and paste in the line above and push the Search/Magnifiying Glass button next to it]

I really dont get this.

More major NATO bases such as Mildenhall and Lakenheath in the UK are completely visible in high res:

52.3636551681, 0.479026865934

52.403339953, 0.556697467456

So what the heck is at Gilze on that day that noone wants us to see? Or are the Dutch just paranoid? European Area 51? Secret Rendition flight on the ground? Anyone? Anyone?

By the way:

Have a look at the B17 on the ground at Duxford in flying condition:

52.0922586315, 0.129379759876

And the old WW1 fighter field at fowlmere back in use with a small twin on the ground:

52.0774049049, 0.061787171553

Did Australia Have the Bomb?

This is an article I've always wanted to write but have never seemed to get around to.

The following is a speculative timeline of Australia's dealings with the bomb and its potential operational control of a device. I have no real evidence that what follows ever happened as stated, but several factors, notably the lack of obvious payoffs for the atomic tests, the bomber selection shortlist and the bizarre race to build a reactor have made me ponder if Australia had operational control of loaned bombs for some time period. Some of the points below are common knowledge, some are covered in the ABC TV documentary "Fortress Australia" and some are based on what may be commonly called "pub stories". Again, I stress this is purely speculative.

1952-1957

Australia is used as the scene of the UK's nuclear development program. Multiple bombs are detonated on the Montebello islands off Western Australia, at Maralinga in South Australia and at Emu Field, also in South
Australia. One of the almost never explored aspects of these tests is what did Australia get for participation in the effort? Cynics might say a vast area of irradiated land and ongoing health problems for thousands of
veterans. Others might say our scientific establishment got to piggyback off UK nuclear research to some small degree.

But what if there was another clause to the agreement for the tests. An unwritten or secret clause that was never made public, and may never be for another 50 years? What is payment for the tests was the bomb itself?
Whilst this may at first seem mad let us consider what form it may have taken.

British bombs with RAF serial numbers and RAF markings may have been based in Australia. At the edge of an airstrip, such as at Woomera, they remain in hardened bunkers, guarded around the clock by RAAF personal, not knowing what was inside. The bombs are, British, but the understanding is that they are under Australian operational control if and when required for the defense of Australia. If an Australian Prime Minister was ever asked if Australia had the bomb he could correctly answer in the negative. If a British Prime Minster was asked if the bomb was ever proliferated to Australia, they could also answer in the negative.

And Australia definitely had a delivery system in the form of the Canberra bomber. Whilst not a perfect, it was more than adequate to deliver a small free fall device.

1955-1961

At some time in this period the British bombs are positioned in Australia. By 1961 the UK nuclear tests reach an end.

1961-1963

Australia decides to upgrade its main strike bomber fleet. The Canberras, whilst excellent aircraft are now outclassed by modern transonic and supersonic fighters so a replacement is sort. The short list of aircraft
selected includes the F-111, the Mirage-IV and the B-58 Hustler. The most amazing thing about this list is the types of aircraft on it.

The Mirage-IV and B-58 are solely supersonic nuclear strike bombers. The Mirage-IV was developed to carry Frances independant nuclear deterrant, before France had balistic missiles. The B-58 was developed as a replacement for the B-52 and was similar to the Mirage-IV in its mission, to deliver nuclear and thermo-nuclear weapons at supersonic speed through the Soviet air defense system. The last runner was the F-111. This aircraft combined the ability to deliver a nuclear payload with that of a non-nuclear heavy tactical and strategic bomber.

The fact that these three aircraft were on the short list points at what the selection criteria must have been: supersonic, multicrew, long range and nuclear capable. But why have a nuclear capable aircraft if you
didnt have the nuclear weapon to deliver?

1963

Australia announces the selection of the F-111 as the Canberra's replacement.

1963

Menzies goverment explores buying or building our own indigenous bombs. Buying is turned down outright by the US and UK whilst neither country will share bomb construction secrets with Australia either due to cold war spy leaks in Australia amongst other reasons.

1964

China explodes first bomb

1965

In October 1965 a new labour government is elected in the UK. The first since 1951.

1965

Indonesia after lurching wildly around the political spectrum enters the year of living dangerous. President Sukarno has previously mentioned building an indonesian bomb whilst recieving the latest Soviet jet aircraft.

1966

In January 1966 Robert Menzies steps down as Australian Prime Minister after 17 years.

1965-1969

In this time frame the UK withdraws from its loaned bomb agreement with Australia. Different governments with different outlooks on both sides of the agreeement could have contributed to this. Possibly a forward point in time, around 1970, was set for their withdrawal....

1967
